Mô tả sản phẩm
| Ethernet | 10/ 100Base-T/Tx1, Automatic MSI/ MDI-xport |
| Communication Port | TxD,RxD,RTS,CTS,DTR,DSR,DCD,GND , Baud rate :1200bps ~ 230.4kbps |
| RS-232 (COM 1) | TxD,RxD,RTS,CTS,DTR,DSR,DCD,GND , Baud rate :1200bps ~ 230.4kbps |
| RS-232 (COM 2) | TxD, RxD, GND ( only CYT-200SC ) |
| RS-485 | 2 DATA+/- |
| RS-422 | 4 R+/R-/T+/T- |
| CPU | 16 Bits, 100MHz |
| Memory | 256K Flash & 2M SDRAM |
| Watch Dog | System halt prevention |
| LED Indicator | CYT-100SC*4： Power / RXD / TXD / ACT CYT-200SC*7： Power / RXD / TXD / ACT/ACT2/RXD2/TXD2 |
| Power Requirement | DC 9V ~ 24V |
| Power Consumption | 500mA(9V) |
| EMI/ EMC Certification | FCC B, CE B |
| System Requirement | Operation Temperature: 0ºC~ 55ºC Storage Temperature: -20ºC~ 75ºC Operation Humidity: 5%~ 80%RH |
| Surge Protection | Serial port 15 KV ESD |
| Magnetic protected | Ethernet port 1.5 KV |
| Connector Type | DB9 (Male)/ RJ-45/ 2 RS-485/ 4 RS-422 |
| Reset Button | Yes |
| Dimension | 106.5 (Include ear loop) x 115 x 28 mm |
| Weight | CYT-100SC*315 g. CYT-200SC*320 g. |
